| Project |
Parameter |
| Print |
Printing method |
Thermal |
| Resolution |
203dpi |
| Maximum print width |
3.15''(80mm) |
| Maximum printing speed |
7 ips(180mm/s) |
| Print length |
0.79''-7.87''(20-200mm) |
| sensor |
Seam mark detection, black mark detection, paper shortage detection, backflow detection, cover opening detection, head temperature detection |
| medium |
type |
Label paper, Bottom black mark, continuous paper, folding paper |
| Width (label + backing paper) |
1.18''-3.35''(30-85mm) |
| Thickness (label + backing paper) |
0.0023''-0.0071''(0.06mm~0.18mm) |
| Maximum paper roll diameter |
φ4.13''(φ105mm) |
| Reel inner diameter |
φ1''(φ25mm), φ1.50''(φ38mm) |
| Paper tearing method |
Manual tearing |
| processor |
32-bit ARM MCU |
| storage |
RAM |
2MB, 4MB (BU), 8M (USE) |
| FLASH |
2MB (U), 4MB (BU) |
| Function |
button |
Rocker switch, Feed button, Paper bin cover opening button |
| Indicator Lights |
YES |
| buzzer |
Buzzer tone |
| Display |
/ |
| other |
Automatic paper recognition, reprinting when out of paper, first sheet return, bad pixel detection |
| Communication interface |
U/BU/USE |
| programming language |
TSPL+ESC, ZPL+ESC |
| Built-in fonts |
ASCll Font: 10x12, 14x20, 16x24, 24x32, 36x48, 14x19, 21x27, 14x25, 12x24 |
| GB18030: 24×24 |
| Code Page |
Extended character table |
CP437, CP850, CP852, CP860, CP863, CP865, CP866, WPC1250, WPC1251, WPC1252, WPC1253, WPC1254 |
| Barcode |
One-dimensional code |
Code39, Code39C, I25, Code93, ITF25, EAN128, Code128, Codabar, EAN-8, EAN8+2, EAN8+5, EAN -13, EAN13+2, EAN13+5, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPCE+5MSIC, ITF14, EAN14, Code11 |
| |
QRCODE, PDF417 (optional) |
| software |
drive |
XP, Win7, Win8, Win10, Win11, ios, Android, Linux, MacOS |
| SDK |
Android, iOS, Windows |
| Label design |
Barcode label editing software (PC), APP |
| Power adapter |
Input: AC 100-240V, 50/60Hz |
| Output: DC 24V/2.5A |
| Environmental parameters |
Work |
Temperature: 32-104℉(0-40℃); Humidity: 20-90% (non-condensing) |
| storage |
Temperature: 14-140℉(-10-60℃); Humidity: 5-95% (non-condensing) |
| Physical parameters |
Dimensions (length, width, height) |
179mm*150mm*142mm |
| weight |
1kg |
| Accessories |
Standard |
Power cord, USB data cable, power adapter, quick installation guide |
| Optional |
|
| standard |
CCC, CE, UKCA |
