1. Simple and elegant, with high optical mirror and sticks appearance
2. Internal important parts are with metalmaterial
3. Easy paper loading, with auto cutter, full cut/partial cut optional
4. 300mm/s high printing speed, rapidly change
supplies, improve work efficiency
5. With auto cutter, paper out alarm
6. Parallel, serial, USB, Ethernet Optional multiple
interfaces (supports two in one, or three in one)
7. Paper end sensor, paper near end sensor (for flat)
8. Support flat,wall-mount
9. Low noise, support high speed graphics and hardware fonts printing 10. Widely used in kitchen, front desk and other places
Key attributes
Interface Type
USB Serial Ethernet Lan Parallel
Black Print Speed
250mm/s
Place of Origin
Fujian, China
After-sales Service
Call Center and on-line Technical Support
Software development kit (SDK)
Yes
Accessory specification
Adaptor, Power Cord, USB Cable
Product Name
80mm Thermal Receitp Printer
Printing Method
Direct Thermal Printing
Paper Loading
Easy Paper Loading
Interface
USB Serial Parallel Ethernet
Driver
WINXP/WIN7/WIN8/LINUX/Mac OS
Certification
FCC CE RoHS CCC
Technical Parameters:
|
|
|
Model
|
RP820 (3inch 80mm bluetooth wifi thermal receipr printer )
|
|
Print
|
Printing method
|
Direct thermal printing
|
|
Effective printing width
|
72mm or 48mm
|
|
Resolution
|
203dpi (8 dots/mm)
|
|
Printing speed
|
300mm/s
|
|
Printing density
|
576 dots/line or 384 dots/line
|
|
Character set
|
GB18030 (Simplified Chinese)
|
|
Print font
|
ASCII Font A:12×24 ； ASCII Font B:9×17 ； Chinese: 24×24
|
|
Character per line
|
Font A- 48 lines / Font B- 64 lines / Chinese-24 lines
|
|
Paper specification
|
Paper width
|
79.5±0.5mm
|
|
Paper roll diameter
|
Φ80mm
|
|
Paper loading
|
Easy paper loading
|
|
Barcodes
|
Barcode type
|
UPCA/UPCE/EAN13/EAN8/CODE39/I25/CodeBar/CODE128/CODE93/CODE11/MSI/QRCORE/ PDF417
|
|
Thermal printing head
|
150km
|
|
Auto cutter
|
2,000,000 cuts
|
|
Interface
|
USB ,Serial ,Ethernet
|
|
Paper out detection function
|
optional
|
|
Emulation
|
ESC/POS/OPOS
|
|
Driver
|
WIN2003/WINXP/WIN7/WIN8/WIN10/LINUX/Mac
|
|
Printer Input Power
|
DC 24V,2.5A
|
|
Adapter Voltage Input
|
AC 100-240V
|
|
Cash drawer Control
|
DC 24V,1A
|
|
Certificate
|
CCC,CE,FCCID ,ROHS,REACH,BIS,UKCA
|
|
Dimension (LxWxH )
|
190×145×140mm
|
|
Printer Net Weight
|
1.4kg
|
|
Gross Weight
|
2.4g
|
|
Environment
|
temperature
|
working temperature: 0~45℃, Storage:-10~60℃
|
|
humidity
|
working temperature: 20-90%, Storage:10-90%(paper exclused)
|
FAQ:
1. Are you a factory or trading company?
Re: We are the professional POS printer manufacturer and top brand in China, owning the professional design group, skill-full staff and quality inspection team, located in 6000㎡ Industry Park, Xiamen city, China.
2. Can you make OEM or ODM for products?
Re: OEM and ODM products are available for customers, as long as customers meet the MOQ. Also, we have engineers for logo and product design for customers.
3. Besides the English language, do your printers support other languages? And what operation system do they backup?
Re:Yes, our printer not only supports the English, but also Russian, Spanish, Portuguese and Arabic etc 48 different languages available. and it supports iOS, Android, WindowsXP/2000/7/8, Linux, Mac OS and OPOS operation systems.
4. What about delivery time?
Re: Samples within three working days and bulk quantity 7-15days.
5. What warranty and after-sale service do you offer?
Re: Each printer will have 1 year warranty. Free components will be offered for repair in the warranty period, if the issue is caused by non-artificial damages.
We will offer technical support and help in your daily use for a lifetime and offer the latest software for your updating.
6. Can you offer driver/SDK for printers?
Re: Yes, we are supplying all driver/SDK for various systems.
7. What about MOQ?
Re: We can accept sample order first. There is no limit for sample order quantity.
